ASTM A193 Grade B7M Fasteners

Short Description:

Fasteners are a type of mechanical components that are widely used for fastening connections. Fasteners are widely used in various industries, including energy, electronics, electrical appliances, machinery, chemical, metallurgy, molds, hydraulic, etc., in various machinery, equipment, vehicles, ships, railways, bridges, buildings, etc.

Send email to us

ASTM A193 Grade B7M Fasteners

ASTM A193 Grade B7M is a high-strength alloy steel bolting specification designed for high-temperature and high-pressure service, with the "M" suffix denoting 100% hardness testing requirements and restricted hardness limits for enhanced quality assurance.

Material Composition & Properties:

• Base Material: Chromium-molybdenum alloy steel (AISI 4140/4142 or equivalent), quenched and tempered

• Tensile Strength: Minimum 100 ksi (690 MPa)

• Yield Strength: Minimum 80 ksi (550 MPa)

• Hardness: 235 HBW maximum (B7M-specific restriction, versus 321 HBW for standard B7)

• Temperature Range: Service from -100°F to +1000°F (-73°C to +538°C)

The "M" Designation Significance:

The B7M grade mandates 100% hardness testing on every fastener (not just sampling), with a lower maximum hardness cap. This ensures:

• Superior uniformity and reduced susceptibility to hydrogen embrittlement

• Enhanced performance in sour gas (H₂S) environments per NACE MR0175/ISO 15156

• Greater reliability in critical pressure-boundary applications

Common Fastener Types:Stud bolts, heavy hex bolts, threaded rods, nuts (typically paired with ASTM A194 Grade 2HM nuts), and custom-engineered fasteners

Primary Applications:

• Petrochemical and refinery pressure vessels and heat exchangers

• Valve and flange connections in high-pressure piping systems

• Offshore drilling and subsea equipment exposed to corrosive hydrocarbons

• Power generation boilers and turbine assemblies

• Sour service environments where NACE compliance is mandatory

Certification:

Full material test reports (MTRs) including chemical analysis, mechanical testing, and hardness verification required for each production lot.
